Type |
Dimensions (mm) |
|||||
|
A |
Bmin |
C |
D |
E |
F |
|
|
UYF12 |
37.0±0.6 |
15.8 |
12.0±0.3 |
8.4±0.3 |
25.0±0.3 |
35.0±0.3 |
|
UYF12.5 |
34.5±0.5 |
11.8 |
12.5±0.3 |
10.0±0.3 |
20.5±0.3 |
30.5±0.3 |
|
UYF13 |
38.3±0.6 |
13.8 |
13.0±0.3 |
11.2±0.3 |
24.7±0.3 |
35.7±0.3 |
|
UYF13.8 |
38.8±0.6 |
13.5 |
13.8±0.3 |
10.7±0.3 |
25.3±0.3 |
36.5±0.3 |
|
UYF13-4B |
35.4±0.6 |
11.9 |
13.0±0.3 |
10.0±0.2 |
20.6±0.3 |
30.6±0.3 |
|
UYF14 |
40.0±0.7 |
15.5 |
14.0±0.3 |
10.8±0.3 |
22.5±0.3 |
34.0±0.3 |
|
UYF15 |
42.5±0.7 |
14.7 |
15.0±0.3 |
12.0±0.3 |
23.3±0.3 |
35.3±0.3 |
|
UYF15A |
42.0±0.7 |
14.5 |
14.9±0.3 |
12.0±0.3 |
25.5±0.3 |
37.5±0.3 |
|
UYF15B |
42.2±0.7 |
14.8 |
15.0±0.3 |
11.8±0.3 |
24.6±0.3 |
36.3±0.3 |
|
UYF16 |
44.5±0.7 |
15.4 |
16.0±0.3 |
12.0±0.3 |
25.8±0.3 |
37.8±0.3 |
|
UYF17 |
48.0±0.8 |
17.5 |
17.0±0.3 |
13.0±0.3 |
23.2±0.3 |
36.2±0.3 |
|
UYF18 Height |
42.0±0.8 |
14.4 |
18.0±0.3 |
9.0±0.3 |
37.0±0.4 |
29.0±0.4 |
|
UYF18 Short |
42.0±0.8 |
14.4 |
18.0±0.3 |
9.0±0.3 |
16.5±0.4 |
8.5±0.3 |
|
Type |
Parameters |
Weight(g) |
|||
|
C1（mm-1） |
Le（mm） |
Ae（mm2） |
Ve（mm3） |
||
|
UYF12 |
1.600 |
162.6 |
104.6 |
17014 |
88.3 |
|
UYF12.5 |
1.160 |
139.0 |
120.0 |
16700 |
83.0 |
|
UYF13 |
1.130 |
154.0 |
136.0 |
20900 |
108.0 |
|
UYF13.8 |
1.110 |
167.0 |
150.0 |
25000 |
122.1 |
|
UYF13-4B |
1.120 |
141.0 |
126.0 |
17700 |
89.0 |
|
UYF14 |
1.140 |
162.1 |
145.7 |
23618 |
121.0 |
|
UYF15 |
0.950 |
163.1 |
171.0 |
27890 |
143.0 |
|
UYF15A |
1.000 |
171.3 |
171.0 |
29292 |
148.0 |
|
UYF15B |
0.980 |
168.5 |
171.0 |
28813 |
146.0 |
|
UYF16 |
0.900 |
175.9 |
189.5 |
33325 |
172.0 |
|
UYF17 |
0.801 |
172.8 |
216.0 |
37290 |
185.0 |
|
UYF18(Tall + Short) |
0.99 |
161 |
162 |
26100 |
Tall83.0 |
|
Short43.0 |
|||||
